Bearing CRO52

SICOMA CRO52 Bearing is used for MAO3000/2000 mixer shaft end sealing group.

CRO52 Bearing

It is used for MAO series mixer sealing group. The seal against the concrete leakage from the mixing tank consist of two rectified steel wheels that turns opposing in pressure. If the grout percolate, or due to a faulty metal seal, the machine can still operate (bearings are separated and far from the seals), but it is recommended to clean the interstice frequently between the bearing and the seal and to substitute the damaged seals at soonest.

SICOMA SEALING GROUP PARTS

Sealing group electric motor side

Sealing group electric motor side

Sealing group opposite electric motor side

Sealing group opposite electric motor side

NO DESCRIPTION QUANTITY CODE
1 SHAFT 2 MOA16
2 STEEL BUSH 2+2 MOB08
3 PROTETION RING(B) 2 SCAJ-400-244 (HEXAGON)(2000, 3000)

SCAJ-230-244 (1000, 1250)

4 PROTETION RING (A) 2 SCAJ-600-243-1(2000, 3000)

SCAJ-230-244 (1000, 1250)

5 PRESS-SLICE 2 SCAJ-600-317

SCAB-230-315-1 (1000,1250)

6 DUSTPROOF RING 2 SCAJ-600-318
7 SEALING COVER 2 MOSAP8

SCAJ-600-316-1

8 COVER 2 SCAJ-600-315
9 YELLOW SEAL 2 SCAB-600-229
10 O RING 2 SCAB-400-239
11 SEAL MOUNTING RIING 2 MOSACOM

SCAJ-400-232/233

12 BLUE SEAL 2 SCAB-600-230
13 RETAINING RING 2 Ф120/Ф125
14 SUPPORT (1) 2 SCAZ-600-156
15 STEEL BUSH 2 SCAJ-400-362
16 SEAL(2) 2 SCAB-400-235
17 COVER(2) 2 SCAZ-600-159
18 SUPPORT(2) 2 SCAZ-400-157
19 SEAL(1) 2 SCAB-400-234
20 BEARING 2 CRO52
21 SEAL(3) 2 SCAB-400-231
22 COVER(3) 2 MOCP4
