SICOMA Screw VB059

SICOMA VB059 Screw TCEI M20X60 UNI 5931

SICOMA VB059 Screw TCEI M20X60 UNI 5931

SICOMA SEALING GROUP PARTS

Sealing Group Opposite Electric Motor Side

Sealing group opposite electric motor side Drawing-6_

NO DESCRIPTION QUANTITY CODE
1 Metallic Seal 2 PA080
2 Lock Washer D.24 UNI 1751 12 RG024
3 Screw TCEI M24X50 UNI 5931 12 VB074
4 Support 2 MOSA13
4A Support 2 MOSA14
4B Support 2 MOSA15
5 Screw TCEI M.10X35 UNI 5931 8 VB009
6 Seal 124-140-13 2 PA059
7 Screw TCEI M.20X60 UNI 5931 12 VB059
8 Lock Washer, D.14 UNI 1751 12 RD014
9 Screw TE M14X45 UNI 5737 12 VEA33
10 Cover 2 MOCP4
11 Seal 105-130-10 2 PA051
12 Bearing 23122 (110-180-56) 2 MOCU3
13 Seal 120-160-13 2 PA084
14 Nut M.6 UNI 7473 8 DAM06
15 Seal 2 V0568
16 Tie-rod 8 MOSAP12
17 Cover 2 MOSAP8
18 Seal 2 PA102
19 Bush 2 MOB08
