PLY300 Batching Controller

Introduction

PLY300 batching controller is an intelligent instrument which is controlled by a single chip microcomputer and integrates weighing and control. The unique anti-interference measures enable the controller to be reliably used in harsh field environment. The controller can meet the needs of automatic batching in various industries such as construction, metallurgy, packaging, feed, etc. The instrument design is based on the relevant contents of the following standards: GB/T 7724-1999 weighing display controller.

Main functions

  • Integrating weighing display and batching controller
  • Complete material batching control function
  • Up to four different kinds of materials can be controlled, and two ways of unloading
  • Two unloading control modes are provided
  • Tank number control function
  • Automatic zero point tracking
  • Key peeling function; Automatic peeling function
  • It has the function of manual preset and automatic correction of drop
  • Use software full digital calibration function
  • Unique test function, convenient for on-site debugging.

Metering characteristic parameters

1 Accuracy level: Level 3.

2 Maximum calibration graduation: 2000.

3 Working temperature range: (0~40) ℃.

4 Error distribution coefficient pi: 0.5.

General specifications

1 Power supply: AC 220V ± 10% 15% or 380V ± 10% 15%, 50Hz ± 2%.

2 Excitation voltage of load cell: 5VDC ± 5%

3 Adjustable range of static load signal voltage: (0~8) mV.

4 Minimum input signal voltage corresponding to each calibration graduation value e( μ V):3 μ V.

5 Measurement range signal voltage: (0~11) mV.

6 Load cell impedance range: 40 Ω~1200 Ω.

Switching value input part

The DC 12V drive power supply is provided internally, which cannot drive other loads except the input contact.

Switching output part

External power supply: DC 24V or AC 220V. Contact capacity: ≤ 1A.
