SICOMA GCE015 Seal OR222

SICOMA Seal GCE015 is used for MAO series mixer hydraulic power pack.

SICOMA GCE015 Seal OR222

Introduction

The hydraulic plant is mainly used in the opening or closing of the silo door of the concrete and asphalt mixing plant. One end is equipped with a handle and a special manual pump device, which avoids the loss caused by the abnormal operation of the hydraulic oil pump due to special circumstances such as power failure. There are horizontal and vertical pump stations, and they are used with hydraulic universal oil cylinders. The hydraulic oil pump motor is usually 2.2KW, and the solenoid valve voltage is 24V and 220V.

Product Features

1. High-quality motor, stable operation and long service life.

2. Equipped with a uniquely designed shunt main body to ensure smooth oil circuit.

3. The output oil pressure can be adjusted by itself to ensure the normal operation of the equipment.

4. Equipped with a high-performance manual pump, which can be switched to manual operation during maintenance.

Hydraulic Power Pack

NO DESCRIPTION QUANTITY CODE
1 Electric Motor 1 M2502
2 Joint 1 GCG01
3 Monobloc 1 GCE01
4 Plug for Oil 1/2” 1 GCE17
5 Key 1 CON89
6 Seal 3/8” 2 GCE18
7 Oil Pipe 1 GCE06
8 Screw M6X16 UNI5931 4 VB025
9 Seal OR114 2 GCE52
10 Screw 3/8” 1 GCE19
11 Plain Washer D6 UNI6592 4 RCO06
12 Screw M6X20 UNI5931 4 VB093
13 Hand pump 1 POM44
14 Screw M8X40 UNI5931 2 VB007
14A Screw M8X20 UNI5931 2 VB005
15 Seal 1 GCE24
16 Oil tank 1 GCES1
17 Level and temp detector 1 IH052
18 Filter 1 FOC01
19 Gear pump 1 POMP1
20 Oil Pipe 1 GCE06
21 Seal OR222 1 GCE015
22 Lock Washer M6 UNI6798 1 RD006
23 Seal OR445 1 GCE04
24 Nut M6 UNI5588 1 DAD06
25 Seal OR445 2 GCE54
26 Level Gauge 3/8” 1 TAO04
27 Screw M8X35 UNI5739 4 VE015
28 Discharge Gauge 3/8” 1 TAG38
29 Stirrup 1 GCE30
30 Plain Washer M8 UNI6592 8 RCO08
31 Nut M8 UNI5588 6 DAE08
32 Screw M8X25 UNI5739 2 VE010
33 Plain Washer M8 UNI6592 4 RCO08
34 Screw M10X25 UNI5931 4 VB011
35 Selector 1 GCE59
