YCT225-4B Adjustable Speed Motor

$1,100.00

-8%

YCT Series Electromagnetic Adjustable Speed Motor
Model:YCT225-4B, 15KW, 367kg
Reference price:1090.00USD (with speed governor)

YCT225-4B, 15kw Electromagnetic Adjustable Speed Motor

YCT series of electromagnetic speed motor has simple control and variable speed AC motors.The motor consists of pulling motor (three-phase induction motor), eddy current clutch,and tacho generator. Usually with the JD series, TZ series of controllers to form a set of negative feedback system with variable speed drive.

YCT Speed motor has been widely used in steel, power plants, cables, of theEngineering, oil, cement, textile, printing and dyeing, paper, machinery and other industrial sectors, for constant torque or decreasing torque of the load machinery for stepless speed regulation purposes, especially suitable for large flow changes in the pump and fan load drag, can get a good energy saving effect.

Technical Parameter

Model Power

(kW)

Rated torque

(N m)

Weight

(kg)

Speed

(r/min)

Model Power

(kW)

Rated torque

(N m)

Weight

(kg)

Speed

(r/min)

YCT112-4A 0.55 3.6 54 1230-125 YCT250-4A 18.5 116 478 1320-132
YCT112-4B 0.75 4.9 55 YCT250-4B 22 137 502
YCT132-4A 1.1 7.1 81 YCT280-4A 30 189 630
YCT132-4B 1.5 9.7 85 YCT315-4A 37 232 830
YCY160-4A 2.2 14.1 122 1250-125 YCT315-4B 45 282 858
YCT160-4B 3 19.2 125 YCT355-4A 55 344 1440 1340-440
YCT180-4A 4 25.2 160 YCT355-4B 75 469 1570
YCT200-4A 5.5 35.1 218 YCT355-4C 90 564 1640 1340-600
YCT200-4B 7.5 47.7 231 YCT355-4D 110 688 1900
YCT225-4A 11 69 344 YCT355-4E 132 821 2010
YCT225-4B 15 94 367

YCT Series Electromagnetic Adjustable Speed Motor download.

YCT MOTOR SIZE, Base mounting;
YCTL-MOTOR SIZE. Vertical installation, Flange installation.
Weight 380 kg
Voltage

380VAC.50Hz, ±10%

Suppliers

HIYAMECH, TRI OCEAN
